Unlock Your Cycling PotentialCall Us at 8591220335 for Expert Advice!
Heist X is a durable urban bike providing a comfort city riding with mountain bike durability for light off-road adventures. Urban bike with MTB soul this bike is one of the best solution for any urban warrior looking for a durable commuting bike providing a comfort riding position & short fun weekend ride on their local singletracks.
Specifications
| Frame |
AL6 URBAN CROSS, 12x142mm O.L.D. 2HRU
|
| Fork |
SUNTOUR NVX, 63mm TRAVE
|
| Head Set |
THREADLESS INTEGRATED HEADSE
|
| Handlebar |
ENTITY XPERT, ALLOY
|
| Rear Derailleur |
SHIMANO DEORE RD-M6000
|
| Shifter |
SHIMANO DEORE SL-M6000
|
| Bottom Bracket |
INCLUDE CRANKSET
|
| Crank Set |
ALLOY 2-PIECE CRANKSET
|
| Cassette |
SHIMANO CS-HG500
|
| Brake |
SHIMANO BR-MT200 HYDRAULIC DISC BRAKE
|
| Wheel Set |
ALLOY DOUBLE WALL 32H
|
| Tire |
WTB RIDDLER TIRE 700X45C
|
| Seat Post |
ENTITY XPERT, ALLOY
|
| Height/cm |
150-160 |
160-170 |
170-180 |
180-190 |
| Size |
S |
M |
L |
XL |
| Heist X |
|
|
|
|
Geometry
|
A |
B |
C |
D |
E |
F |
G |
H |
I |
J |
K |
L |
M |
| Size |
Seat Tube Length |
Seat Tube Angle |
Effective Seat Tube Angle |
Head Tube Length |
Head Tube Angle |
Effective Top Tube |
BB Height |
BB Offset |
Chainstay Length |
Wheelbase |
Frame Reach |
Frame Stack |
Standover Height |
| S |
400 |
74 |
74 |
90 |
71 |
563.12 |
289.5 |
70 (Drop) |
440 |
1063.12 |
385 |
621.18 |
688.3 |
| M |
431 |
74 |
74 |
90 |
71 |
593.12 |
289.5 |
70 (Drop) |
440 |
1093.12 |
415 |
621.18 |
708.7 |
| L |
470 |
74 |
74 |
100 |
71 |
620.8 |
289.5 |
70 (Drop) |
440 |
1121.43 |
440 |
630.64 |
742.5 |
| XL |
516 |
74 |
74 |
110 |
71 |
648.54 |
289.5 |
70 (Drop) |
440 |
1149.63 |
465 |
640.1 |
781.5 |
